Description
Specification
Environment conditions
Operation
a) Environment temperature: +5℃~+35℃
b) Relative humidity: ≤80%
c) Power supply: AC:100V~240V, 50/60Hz
DC:18V, 3500 mAh rechargeable lithium battery
d) Atmospheric pressure: 86kPa~106kPa
Transportation and Storage
a) Environment temperature: -40℃~55℃
b) Relative humidity: ≤95%
c) Atmospheric pressure: 50kPa~106kPa
- Input way: Floating and defibrillation protection
- Sampling precision: 12 bits
- Lead: Standard 12 leads(model:BIP0057)
- Patient leak current: <10μA
- Input impedance: ≥50MΩ
- Frequency response: 0.05Hz~150Hz(-3dB~+0.4dB)
- Time constant: Time constant≥3.2s
- CMRR: >60dB, >100dB( Adding filter)
- EMG filter:25Hz/35Hz (-3dB)
- AC filter:50Hz/60Hz (≥20dB)
Accessories
- ECG lead wire 1 set
- Limb electrode clamp 1 set
- Chest electrode 1 set
- Power cord 1 piece
- Ground wire 1 set
- Thermal recording paper 1 set
- User manual 1 set
- Optional:
ECG data line
External ink jet printer
3G and WIFI
