Specification
· Dimension and Weight
– Dimension: 315mm*230mm*236mm
– Weight: 2.8kg（excluding accessories）
· Power Supply
– Voltage: AC100～240V, 50/60HZ
– Adapter: Output 9VDC, 5A
· Display
– 8″ color TFT LED
– Resolution: 800*600 pixels
· Battery (Built-in)
– Type: Rechargeable lithium battery
– Charge Cycle: ≥500 times
– Working time: 2 hours (optional larger battery for 4-5 hours)
· Recorder (Built-in)
– Method: Thermal printer
– Paper: Z-fold, thermosensitive
– Paper width: 112 mm (4.41 in)
– Printing speed: 1/2/3cm/min
– Trace: Max. 4 tracks
– Recording way: Real-time Recording & Review Printing
· Alarm
– Level: Low, medium and high, message
– Indication: Auditory, Visual, Delay of FHR Alarm
· Input & Output
– Standard: Touch pad
– Option: USB Mouse / Keyboard
– USB port for patient data/Auto CTG analysis backup (option)
– USB port for external laser printer (option)
– Laser printer interface
· System Output & Extensible Interface
– Ethernet Network: standard RJ45 socket *1
– USB Port * 1
– HDMI port (option) * 1
· Safety
– IEC60601-1 Approved, CE marking according to MDD93/42/EEC
– With reference to RoHS Directive 2011/65/EU recasting
· Ultrasound (FHR)
– Measure method: Wide beam pulse doppler
– FHR Measurement range:
30 to 240 bpm (US Standard)
50 to 210 bpm (Europe Standard)
– Accuracy: ±1 bpm
– Intensity: ＜3 mW/cm2
– Ultrasound frequency: 1MHz±3%, 2 / 2.5 / 3MHz can be customized
– Resolution: 1 bpm
· TOCO
– Measurement method: Strain gauge sensor element
– Measure range: 0 ~ 100 units
– Resolution: 1 unit
– Nonlinear deviation : ≤±8%
– Baseline setting: 0,5,10,15, 20 can be selected
– Auto offset correction, Auto zero adjust
· Fetal Movement Recording
– Automatic fetal movement (AFM): pulsed doppler ultrasound
– Automatic fetal movement autograph
– Manual fetal movement marker (MFM)
* Specifications subject to change without prior notice
